Venus1 Series Fiber Laser Marking Machine
Fiber laser marking machine for precise, stable marking on metals, coatings, automotive parts and industrial components.
Model features
- Fiber laser marking machine for precise marking on metals and coating materials
- Suitable for medical devices, automotive parts, industrial bearings and aerospace components
- High beam quality supports smooth, high-depth and high-precision marking
- Independently developed system with optimized algorithms for efficient marking
- WYSIWYG editing interface with visual device status display
- Abundant external interfaces for connection and interlocking with peripheral devices
- Available in 20W, 30W, 50W and 100W power options.
Technical specifications
Printing parameters
- Laser wavelength
- 1064nm
- Laser power
- 20W / 30W / 50W / 100W
- Positioning method
- Automatic red light positioning, focusing, preview
- Marking speed
- Depends on the size and complexity of the surface material and the marking content
- Number of print lines
- Unlimited
- Character height
- from 0.6 mm up to the marking-field size
- Interface languages
- English, Simplified Chinese, Traditional Chinese, Korean, Japanese, Russian, Spanish, Persian and other languages
- Supported graphic formats
- JPG, BMP, PNG, DXF, DWG, PLT, AI, SVG
- Supported barcodes and 2D codes
- CODE11, C25INTER, CODE39, EXCODE39, EAN128, CODABAR, CODE128, CODE49, CODE93, UPCA, UPCE, EAN14, VIN, NVE18, ITF14, QRCODE, DATAMATRIX, MICROQR, PDF417, PDF417TRUNC
- Marking field
- Standard 110mm * 110mm, optional 50–300mm
- Galvanometer scanner
- High-precision 2D digital scanning system
- Product speed monitoring
- Support AB phase encoder
Equipment and connectivity
- Display
- 10.1-inch color display, industrial touch screen
- Operating system
- Embedded Linux security operating system
- Cooling system
- Air cooling
- Communication interfaces
- Photoelectric signal, encoder signal, alarm signal, I/O, NPN, PNP, switch sensor, RS232 communication
- Power supply
- Input 100V-240V / 50–60Hz
- Power consumption
- ≤600W
- Enclosure material
- Aluminum alloy
- Ingress protection
- IP43
- Dimensions
- Host 585mm * 160mm * 189mm for 20W, 30W and 50W models, host 597mm * 160mm * 289mm for 100W model
- Operating environment
- External temperature 0°C-45°C, humidity ≤95%, non-condensing, no vibration
- Rated laser-source life
- Up to 100,000 hours
- Packaging dimensions
- 790mm * 380mm * 310mm for 20W, 30W and 50W models, 710mm * 360mm * 400mm for 100W model
- Gross weight
- 18kg for 20W, 30W and 50W models, 24kg for 100W model
